Product Details:

Place of Origin: DongGuan
Brand Name: DahoMeter
Model Number: HR-150A / HR-150C

Payment & Shipping Terms:

Minimum Order Quantity: one set
Price: USD999 to 1999 per unit
Packaging Details: standard exporting wooden package
Delivery Time: 25 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
Contact Now
Detailed Product Description
Usage: Rockwell Hardness Tester Testing Before Delivery: Yes
After-sale Customer Service: Yes

Rockwell Hardness Tester Manual , Type of Tablet Hardness Tester



Brief Introduction:

This instrument is in accordance with the Rockwell measuring principle.it can do the testing of Rockwell hardness directly.It has the feature of easy operation,stable reading,convenient maintenance.This instrument is the new design loading and unloading easy operation all-in-one machine,improve the operation procedure compared to the old products HR-150A.which makes machine more stable,durable,and efficient.



Application:

Ferrous metal,non-ferrous metal,non-metal materials;

Quench,tempering.,etc heat treatment materials;

Tempered steel,annealed steel,quenched steel,surface hardened steel,chill casting,forging,hard alloy steel,aluminum alloy,bearing steel,hardened sheet steel.



Features:

  • Accurate data,high testing efficiency.
  • Leverage of loading,manual operation,durability and reliability
  • Non-friction spindle,high accuracy.
  • HRA,HRB,HRC scale can be read directly through dial plate.other Rockwell scale is available.
  • Adopt precision oil pressure buffer,loading speed is adjustable.
  • Mechanical manual testing process.no needs electric controlling.
  • Widely apply to quality monitoring on production site.good working environment adaptability
  • 8. The accuracy is in accordance with GB/T230.2,ISO 6508-2 and US ASTM E18.



Main Technical Specification:

  • Measuring range:20-88HRA,20-100HRB,20-70HRC
  • Testing force:588.4,980.7,1471N(60,100,150kg)
  • Allowed maximum height of testing specimen:170mm
  • Distance from centre of pressing head to machine wall:135mm
  • Hardness resolution:0.5HR
  • Exterior size:466*238*630mm
  • Weight:Around 75kg

Main Accessories:

Big testing table:one pcs;diamond circular cone indenter:one pcs;

Small testing table:one pcs;1/16’’stell ball indenter:one pcs;

V shape testing table:one pcs;standard rockwell hardness block:5 pcs.
