Benchtop Small Climate Test Chamber

Benchtop Small Climate Test Chamber

    • Benchtop Small Climate Test Chamber
    • Benchtop Small Climate Test Chamber
    • Benchtop Small Climate Test Chamber
    • Benchtop Small Climate Test Chamber
    • Benchtop Small Climate Test Chamber
  • Benchtop Small Climate Test Chamber

    Product Details:

    Place of Origin: DONGGUAN,CHINA
    Brand Name: Dahometere
    Certification: ISO,SGS
    Model Number: DH-225

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD5667
    Packaging Details: wood standard exported package
    Delivery Time: stock
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Temperature Deviation: +-2.0℃ Humidity Fluctuation: +-2.5%R.H
    Temp.fluctuation: +-0.5℃ Humidity Range: 20~98% R.H
    Volume: 225L Temperature: -70°C

    Benchtop Small Climate Test Chamber



    This equipment can keep the temperature and humidity setup by users.Its' value can be alternative changed through the software.The device is application to test and confirm the property of heat-resisting,cold-resisting,drying-resisting,humidity-resisting.,etc.It is widely used in the field of electron,electric equipment,communication,instrument,car,plastic,metal,food,chemical,building materials,medical,spaceflight.,etc.





    (1)The outer case is made up of SECC steel plate with spraying plastic.CNC processing molding,Beautiful design,Reactionless holder,easy operation
    (2)Large LCD touching screen
    (3)Adopt micro-computer temperature humidity controller.accuracy and reliability
    (4)Large watching window;floodlight,of which can keep inside of chamber light;3 layers of vacuum glasses;can observe the status at any time
    (5)Individual temperature limitation alarm system;automatically cut off when exceed temperature limitation;which can assure the safe testing
    (6)Equipped with the testing hole with the diameter of 50mm at the both side of testing chamber.can be connected with outter power cable or signal cable
    (7)Adopt high quality fixed PU running wheel in the bottle of machine
    (8)New program temperature humidity chamber can save power more than 45% compared than the traditional type.can save responding time be around 50%.can deduct water consumption be around 80%





    Model DH-23 DH-64 DH-80 DH-100 DH-120 DH-150 DH-225 DH-408 DH-800 DH-1000
    System Balanced temperature&humidity control system
    Temp.range -20℃ ~ +150℃;-40℃ ~ +150℃;-70℃ ~ +150℃(Rapid temperature,linearity,nonlinearity is optional)
    Humidity range 20~98% R.H
    Temp.fluctuation +-0.5℃
    Humidity fluctuation +-2.5%R.H
    Temperature deviation +-2.0℃
    Humidity deviation >75%RH(+2,-3%RH),<75%RH(±5%RH)
    Heat up time -20℃ to +150℃ about 45 minutes;-40℃ to +150℃ about 60 minutes; -70℃ to +150℃ about 75 minutes
    Cooling time +20℃ to -20℃ about 40 minutes; +20℃ to -40℃ about 60 minutes;+20℃ to -70℃ about 85 minutes
    Internal dimension W 30 40 40 50 50 50 60 68 100 100
    H 30 40 50 50 50 60 75 80 100 100
    D 25 40 40 40 48 50 50 75 80 100
    External dimension W 50 60 60 70 70 70 80 88 120 120
    H 125 140 155 155 155 161 171 176 195 195
    D 90 110 110 115 123 125 125 150 155 175
    Interior material SUS#304 stainless steel plate
    Exterior material Backed painting steel or stainless steel(SUS304)
    Insulation material Rigid polyurethane foam + glass fiber
    Refrigeration system Air cooling(water cooling type is option)
    Single section/cascade type,hermetic/semitight compressor,CFC free refrigerant
    Controller Color LCD screen in English,program communicating function
    Safety device No welding wire switch,compressor overheating and over current protection,over temperature protection,blower overload protection,dry heating machine protector.low water protection,fault warning system
    Standard accessories One piece of observation window,one piece of test hole(diameter 5cm),two sets of test racks,one piece of floodlight,one piece of indicator light,four pieces of moving wheels,one piece of himidifying tank,2 meters of power cord,communication interface
    Ambient temp. 5℃ to 35℃
    Power AC380+-10% 50HZ 3 phase 4 wires + Ground wires
