Place of Origin: | Dongguan, China |
Brand Name: | Quarrz |
Certification: | CE,FCC,ISO |
Model Number: | AU-300V/AU-600V |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiable |
Packaging Details: | Negotiable |
Delivery Time: | In stock |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 300 SETS per month |
Usage: | Oil Content And Density Tester | Weight Resolution: | 0.005g |
---|---|---|---|
Testing Before Delivery: | Yes | After-sale Customer Service: | Yes |
Oil Content Resolution: | 0.1% | Power Supply: | AC100V~240V 50HZ/60HZ (Europe Standard) |
Density Resolution: | 0.001g/cm3 |
Portable Oil Density Meter, Oil Content Analyzer, Oil Density Tester AU-300V/AU-600V
Application:oil content,powder metallurgy,electric tools,air tools,mechanical parts,fan industry,motor industry,micro-motor,electrical industry,new materials researching laboratory.
Standards:In accordance with GB/T5165,ISO 2737,GB/T5164,ISO 2738,ASTM B311,B328,GB/T5163,JIS Z2505,JIS Z2506,MPIF Standard42,MPIF Standard45…
Oil content can be displayed by three procedure.it has changed the manual computation method;save time,quick,convenient;it is very suitable to test oil content for copper-base,iron-base,iron copper-base of transmission parts.
Measuring resolution:
AU-120V,AU-200V density resolution:0.0001g/cm3,oil content resolution:0.1%
AU-300V,AU-600V,AU-900V,AU-1200V density resolution:0.001g/cm3,oil content:0.01%
Function and Feature:
Oil length measuring procedure:
Standard Accessories:
(1)host(2)water tank(3)testing board(4)tweezers(5)thermometers(6)weight(7)windproof dustproof cover(8)power transformer
Anti-counterfeiting Announcement:
The bad and good products is intermingled on market today.Most customers had suffered a lot from the brand replacement products,shell brand products,simulation products,and transferring after-sale service products.To protect your rights,please identify seriously when choose goods.Following is the method to distinguish QUARRZ brand product.
Method one:Start up,machine will display in sequence:brand,model(such as QUARRZ,AU-300S)
Method two:After starting up,press ZERO key and B key at the same time,the machine will display in sequence:brand:model,factory number.of which information correspond to the one marked on machine.
Method three:Check security code that generate automatically by machine number.
Technical Specification:
Brand | Quarrz | ||||||
Model | AU-300V | AU-600V | AU-900V | AU-1200V | AU-120V | AU-200V | |
Weight | range | 0.005~300g | 0.005~600g | 0.01~900g | 0.01~1200g | 0.001~120g | 0.001~200g |
Standard deviation | 0.005g | 0.005g | 0.01g | 0.01g | 0.001g | 0.001g | |
Density | readability | 0.001 g/cm3 | 0.0001 g/cm3 | ||||
Testing Board | ABS injection moulding | Aluminum alloy die-casting moulding | |||||
range | 0.001~99.999g/cm3 | 0.0001~99.9999g/cm3 | |||||
Oil content resolution | 0.1% | 0.01% | |||||
Result display | Oil content,density,oil total volume,oil volume can be read directly. | ||||||
Measuring principle | Archimede principle substitution method | ||||||
Measuring time | Around 10 to 60 seconds | ||||||
Opening lid method for testing board | Rapid unobstructed without lifting lid design | ||||||
Water tank |
Completed injection moulding transparent PC water tank(size:length15.3 cm×witdth10.7 cm×height9.3cm) |
||||||
Parameter setting |
Water temperature setting,measuring medium density setting, lubricating oil medium density setting,air buoyancy setting. |
||||||
Calibration method | Single key calibration,automatically detection | ||||||
Standard components |
(1)host(2)water tank(3)testing board(4)tweezers(5)thermometers (6)weight(7)windproof dustproof cover(8)power transformer |
||||||
Interface | Standard RS-232 interface | ||||||
Optional accessories | AU-40 printer,data connecting wire | ||||||
Power supply | AC100V~240V 50HZ/60HZ (Europe standard) | ||||||
Gross weight/size | 4.5kg/Length42.5 cm×Width17.5 cm×Height32.5cm |
