    Product Details:

    Place of Origin: Dongguan, Guangdong
    Brand Name: DahoMeter
    Certification: CE,FCC
    Model Number: DH-1000

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: USD999 to 9999 per unit
    Packaging Details: standard exporting wooden package
    Delivery Time: 15 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Interior Dimensions (WxHxD)cm: 100X100X100 Humidity Range: 20~98% R.H
    Temp.humid Range: 0°C/-20°C/-40°C/-60°C/-70°C~+100°C(+150°C) Internal Volume(L): 1000L

    China Constant Temperature and Humidity Environmental Testing Chamber , Temperature and Climate Test Chambers

    Usage:
    This equipment can keep the temperature and humidity setup by users.Its' value can be alternative changed through the software.The device is application to test and confirm the property of heat-resisting,cold-resisting,drying-resisting,humidity-resisting.,etc.It is widely used in the field of electron,electric equipment,communication,instrument,car,plastic,metal,food,chemical,building materials,medical,spaceflight.,etc.

    Features:
    (1)The outer case is made up of SECC steel plate with spraying plastic.CNC processing molding,Beautiful design,Reactionless holder,easy operation
    (2)Large LCD touching screen
    (3)Adopt micro-computer temperature humidity controller.accuracy and reliability
    (4)Large watching window;floodlight,of which can keep inside of chamber light;3 layers of vacuum glasses;can observe the status at any time
    (5)Individual temperature limitation alarm system;automatically cut off when exceed temperature limitation;which can assure the safe testing
    (6)Equipped with the testing hole with the diameter of 50mm at the both side of testing chamber.can be connected with outter power cable or signal cable
    (7)Adopt high quality fixed PU running wheel in the bottle of machine
    (8)New program temperature humidity chamber can save power more than 45% compared than the traditional type.can save responding time be around 50%.can deduct water consumption be around 80%


    Specification:

    ModelDH-080DH-150DH-225DH-408DH-800DH-1000

    Interior dimensions

    (WxHxD)cm

    40X50X4050X60X5050X75X6060X85X80100X100X80100X100X100

    Exterior dimenstions
    (WxHxD)cm

    97X136X97107X146X107107X161X117117X171X127155X185X130155X185X147
    Internal volume(L)801502254088001000
    Temp.humid range0°C/-20°C/-40°C/-60°C/-70°C~+100°C(+150°C);20%RH-98%RH
    PerformanceConstancy±0.2°C;±2.5%RH
    Uniformity±2°C;±3.0%RH
    Heating up time100°C150°C100°C150°C100°C150°C100°C150°C100°C150°C100°C150°C
    25min35min30min40min30min40min30min40min35min45min35min45min
    Pull up time0-20-40-700-20-40-700-20-40-700-20-40-700-20-40-700-20-40-70
    304565100304565100304565100304565100304565100304565100
    Power(k.w)4.555.56.555.567.55.566.58.566.579.56.577.510.577.5811.5
    Weight(kg)200250300400600700
    MaterialInterior materialStainless steel plate(sus304)
    Exterior materialStainless steel plate(sus304)
    Insulation materialRigid polyauethane foam and glass wool
    Accessories

    Cable hole lid (ɸ50),2pcs/shelves plate,5pcs/Sand cloth,1pcs/lamp,
    1set/product description

    Safety deviceNo-fuse breaker,fuse,over-temperature protection,anti-dry protection,water shortage protection,liquid level protection,compressor overpressure,overheating,overcurrent protection,emergency stop and other protective devices
    Power1ɸ3W AC220V±10% 50/60Hz 3ɸ5W AC380/415V±10% 50/60HZ
