| Brand |
DAHOMETER |
| Model |
DA-300T |
DE-120T |
| Density resolution |
0.001g/cm3 |
0.0001 g/cm3 |
| Weight range |
0.005g~300g |
0.001~120g |
| Density range |
0.001g/cm3-99.999g/cm3 |
0.0001-99.9999g/cm3 |
| Solid mode |
Measuring solid items |
Density of all forms of solid,including metal,rubber,plastic,film,floating body,powder
,foam,viscous body,structure,tubing,wood,sponge,glass,pitch,cement,soil,gem,
paper,concrete,
|
|
graphite,coal,rock,ceramic.etc.(cover the products of hydroscopicity,non-absorbency
,high-viscosity)
|
| Measuring mode |
Archimedes principle |
| A.general solid measuring method |
| B.porosity materials saturation mode |
| C.porosity materials surface covering method mode. |
| D.professional constant volume mode method |
| E.professional rubber abrasion loss and expansibility mode method |
| F.professional hydroscopicity mode method |
| G.professional oil length mode method |
| Measurable project |
density of general non-absorbency solid |
| density of porosity materials |
| oil length of oil bearing |
| porosity of porosity materials |
| DIN volume abrasion loss of rubber |
| powder density |
| water absorption rate |
| Measuring time |
about 5 seconds |
| Memory method |
memory in shorter time by one procedure |
| Specific gravity measurement frame |
completed injection forming professional specific gravity measurement frame |
| (size:length13.5mm×wide5mm×high11.6mm) |
| Measurement tank |
completed injection forming transparent professional measurement tank |
| (size:length16.9mm×wide9.8mm×high8.3mm) |
| Result display |
Display according to the model:density,specific gravity,apparent density,volume density,wet density,total porosity,effective porosity,oil content,water absorption,wear loss,wear |
| index,expansibility,volume and so on. |
| Function setting |
water temperature setting,density setting of medium of comparative solution,density setting of medium of waterproofing treatment ,bound setting,aerostatic buoyancy setting, |
| Loss value setting of fixed weight of reference glue,loss value setting of weight of reference glue,density setting of reference glue. |
| Mixed |
Function introduction |
automatically read the percentage of the main material in the two kinds of mixed materials |
| material percentage |
setting |
freely set the density value of main material and subordinate material |
| |
display |
density value,percentage of main material |
| Liquid mode |
Measurement type |
a:mobility liquid,vicidity liquid,volatile liquid,corrosivity liquid,high temperature |
| liquid,suspension liquid,emulsion and so on. |
| b:alcohol,scaling powder,essence,blood,sodium chloride,glycerol,electrolyte,diesel, |
| refrigerating,hydrofluoric acid,dichloromethane,vitriol |
| Measurement principle |
Archimedes principle displacement method |
| Measurement mode |
3 groups |
| Measurement time |
about 5 seconds |
| Memory mode |
memory in shorter time by one procedure |
| Result display |
density and baume |
| Specific gravity measurement frame |
stainless steel specific gravity measurement frame |
| Function setting |
Temperature setting,density setting, measurement weights setting of standard sensor ball and weights setting in the water |
| Measurement testing |
distilled testing |
| Calibration mode |
auto correction with one button,auto detection. |
| Output mode |
standard interface of RS-232,output and print testing data conveniently |
| Standard accessories |
host,tank,testing board,tweezers,thermometer,100G weight,windproof and dustproof dust cover,a set of measuring floating body parts ,power transformer,DE-20A standard liquid measurement assembly |
| Optional accessories |
DE-40 printer,DE-20B anti corrosive liquid measurement assembly |
| Power supply |
AC~220V / 50HZ;customer can choose other international standards |
| Main features |
data display,accuracy,speediness,convenience;durable,economy |
