DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine

DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine

    • DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine
    • DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine
    • DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine
    • DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine
  • DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine

    Product Details:

    Place of Origin: Dongguan, China
    Brand Name: DahoMeter
    Certification: CE,FCC
    Model Number: Thick 880

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: Negotiable
    Packaging Details: standard exporting wooden package
    Delivery Time: 5-7 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Analysis: 1 PPM To 99.99% Plating Thickness: Within 50 μm (each Material Varies)
    Test Time: 30 SEC ~ 100 SEC Light Pipe Voltage: 0 Kv To 40 Kv
    High Voltage Power Supply: 0 ~ 40 Kv Accuracy: 0.05% Or Less

    DXP-3000 Handheld Spectrum Analyzer



    DXP-3000 Handheld Spectrum Analyzer, Safer Protection Optical Spectrometer,Convenient Operation Handheld Test Machine



    Specification:



    Analysis 1 PPM to 99.99%

    Accuracy of 0.05% or less

    Solid, powder, liquid items under test form

    Light pipe 0 kv to 40 kv voltage

    High voltage power supply 0 ~ 40 kv

    Light control current 0 mu A ~ 100 mu A

    filter Can choose a variety of customized switch

    The probe Sipin

    Resolution of Si - pin145 + 5 ev

    Multichannel analyzer DMCP

    Test time 30 SEC ~ 100 SEC

    Measuring elements from sodium (Na) to uranium (U) between all the elements

    Analysis software KEY qualitative and quantitative analysis software

    Shape size 220 * 300 * 220 (mm)

    The total weight of instrument weight 1.58 Kg (with battery)



    Instruments and environmental requirements

    Ambient temperature - 20 ° C ~ 55 ° C

    < 90% relative humidity



    Features.



    More convenient operation.

    Lightweight, small in size, ergonomic handle design, easier to grip, more convenient to use in the field.



    Sealed all-in-one design with water, water and dust protection for continuous use in harsh environments.



    Samples do not need to be prepared and can be measured directly on the surface of the object. The instrument can be used for quick testing in hand or for long periods of fine testing of samples using the test station (optional).



    Better performance.

    Non-destructive fast detection, alignment on-the-go, one second can report the results and the gold medal number. Performance is comparable to a desktop computer, the detection effect is fast and accurate.



    At the same time, the detection of titanium, vanadium, chromium, manganese, iron, cobalt, nickel, copper, zinc, palladium, palladium, vanadium, palladium, palladium, silver, tantalum, tin, tantalum, tantalum, tantalum, tantalum, tantalum, tantalum, platinum, gold, lead, tantalum elements, and can be customized according to customer needs to add elements.



    Higher-end configuration.

    The introduction of four core technologies, such as micro light tube, new Si-PIN detector, micro digital signal multi-processor and intelligent analysis module, makes it have similar test accuracy.



    The use of ultra-high main frequency and large memory, large storage space, can store data in large quantities. The newly developed digital multi-channel technology guarantees an effective spectral count of up to 500kcps per second.



    Safer protection.

    Intelligent three-color early warning system: LED three-color long light belt design, 360 degrees no dead end display. Green light when power on, test red light flashing, equipment failure yellow light flashing, instrument status, at a glance.



    Secure linkage lock device, when the software can not control off, tap, the first time to protect your security, guard the last level.



    Smarter software.

    Key3000 handheld X fluorescent alloy analyzer equipped with specialized applications specifically for the alloy industry, with intelligent, high sensitivity, short test time, easy operation and so on.



    New intelligent software, one-click intelligent operation, dual-mode design (user mode and expert mode). User mode one-click identification sample material testing, expert mode can add elements, add specific curves and other in-depth analysis operations.



    Built-in strength correction method to correct deviations caused by samples with different geometric states and uneven structural densities.
